engine overhaul

The 5speed SS50 engine that was under the motorcycle was leaking some oil from the cylinder base and behind the generator cover, so it needed to be taken apart, even though it has only done about 500km.
The problem at the cylinder base turned out to be a cylinder that wasn't flat, so it was turned on the lathe to get a flat surface for the gasket to sit against.
I thought it would also have a leaky cranckshaft oil-seal, but it was dry in the center of the generator. Next guess was the O-ring around the stator plate, when I took it off the plate, it was so dried out, that it broke instead of stretching.
So hardened it doesn't even lose its shape when broken:

when the head was off, I took some pictures of it, next to my "old-school tuned engine" this has an older type head with even bigger fins:

and more importantly, nicer ports:

Both are cylinderheads from the 5speed models, with extra and bigger fins then the 3 and 4speed models, but even then there are differences.

The other head has since been flowed to look more like the "old-school" one


Tuesday I took the moped to work, but when driving home, it began to vibrate at high revs and it made some funny noises. 5KM later I was at the workshop, had a quick look if the flywheel nut might have come loose, but it didn't, so I thought it should be a clutch problem. After all these years of abuse, I finaly managed to break the engine.

Today I started disassembly by taking of the exhaust to have a look at the clutch, but to my surprise, it turned out to be as simple as a broken motormount bolt.

I had a new bolt, put it in, put the exhaust back on, started the bike, and the vibrations were gone, engine still in working order, dispite years of abuse.
This motor has almost no compression, you can hear the piston ratteling in the cylinderwall, it never gets new oil, at best the old stuff out of a race-engine, it gets overrevved, overheated with burnouts..... but I still can't get it to really break. Real Honda quality, no chinese parts.

Jet problems

The SS50 motorcycle engine is now pretty much run in, but the carb settings are a litlle of. So I thought I would try a different main jet but to my surprise the keihin SS50A carb is so old that it doesn't have the standardized jets still used today. Now available are jets with 4mm and 5mm treads, as far as I know M4 and M5, but mine has a coarser thread M5x1 ???
In any case it has the same threads as the jets used in the CB72 PW22hov carbs I have, the powerjet type.

some measurements:
5mm threads

6mm head

8mm long

and a view of the coarse threads

If anyone knows where to get these old jets, please let me know, I need something like a 75 or 78

BMW test

I've been riding my R90/6 for a little while now, and I am starting to get used to it, but at first I thought it was a real heavy beast that didn't want to go round corners. Making it into a caferacer would then only make that worse, with narrow clip-on bars and such.

When I was young (about 15 years ago?) my dad built a BMW caferacer together with Jan Hoogstraten who stil ownes the bike. We asked him if we could borrow it for me to experience what a BMW caferacer would feel like. Here it is next to my R90/6

I've only ridden it for a few kilometers now, but it isn't disappointing, I want to ride it some more, to get a good feel of the bike, but I think I'll keep my R90/6 to turn it into the JBT-interceptor styled caferacer I had planned.

The M10s on the back is the name of the bike, being compiled of the enginetype; R90s and my dad's name; Martien ("tien" means "10" in dutch)
Note the single sided paralever swingarm from a later type.
